Green Beast Verification

Layer 1 Verification

Note: This overbraided preform has only ONE layer. Inspection of multilayer preforms will include data for each preform layer and an overall summary, delivering a complete quality package.

Layer 1 Bias Angle

Green Guy Station	Bias Angle	Minimum Bias Angle (Degrees)	Maximum Bias Angle (Degrees)
Station 1	61.5°	58°	64°
Station 2	53°	50°	56°
Station 3	67.75°	65°	71°
Station 4	45°	42°	48°

Layer 1 Ply Cut Location

Green Guy Station	Ply Cut Location Pass or Fail	Ply Cut Location Minimum	Ply Cut Location Maximum
	N/A	N/A	N/A

Layer 1 Thickness

Green Guy Station	Ply Thickness	Total Preform Thickness
Station 1	0.019″	0.019″
Station 2	0.021″	0.040″
Station 3	0.018″	0.058″
Station 4	0.023″	0.081″

Layer 1 Defects

Green Guy Station	Allowable Defects
ALL	None
